Science Image Studio Edge 1CH – 1-channel 1U Rack-mount Bi-Directional 4K SDI / HDMI Full NDI Converter

1-Channel Rack-mount Full NDI Converter with Fiber TX/RX and Analog Audio In/Out
Bi-Directional High-Bandwidth NDI Encoder & Decoder
Up/Down/Cross Conversion of 27 formats
Video I/O: 1x 12G-SDI Input & Output, 1x HDMI 2.0 Input & Output, up to 2160p60
Audio I/O: 1x 3.5mm stereo headphone output, 1x 3.5mm stereo line-in input
Display: 1x 1.3-inch OLED screen with status, video format, IP address, etc.
Control: 1x Scroll wheel buttons for direct menu operation, Web UI control
Tally: 1x Tally LED compatible with NDI tally signals
Audio function: Audio Embed/De-Embed from stream, 2-way Intercom per channel
Network: 1x RJ-45 Gigabit Ethernet, 1x optical fiber SFP+ interface (for optional 12G-SDI transceiver)
Power: AC power input, 1x LED illuminated power button
