AIDA Imaging PTZ-NDI-X12 NDI®|HX FHD NDI/IP/SDI/HDMI/USB3 PTZ Camera 12X Zoom

AIDA Imaging PTZ-NDI-X12 NDI®|HX FHD NDI/IP/SDI/HDMI/USB3 PTZ Camera 12X Zoom

$1,050.00 USD
$1,050.00 USD
Sale Sold out

Reducing camera operators to one!

PTZ cameras are the bread and butter of dynamic live production shots. It doesn’t matter where the PTZ is placed, this camera will see it all. Equipped with 12x optical zoom, the PTZ-NDI-X12 has a plethora of camera features, ranging from camera control to simultaneous Full-HD Outputs to NDI|HX. This camera was made for broadcast application, huddle rooms, or houses of worship. When it comes to the PTZ-NDI-X12 to step up to the plate, we can guarantee you it will perform.

Specifications


Video


Image Sensor 1/2.5″ Progressive CMOS
Effective Pixels Horizontal: 1920, Vertical: 1080
Pixel Size 2.13 µm x 2.13 µm
Resolution 1080p & 1080i: 1920 x 1080
Resolution | Rate 108060p/59.94p/50p/30p/29.97p/25p/24p/23.98p
1080 60i/59.94i/50i
720 60p/59.94p/50p/30p/29.97p/25p
IP Rate 1920 x 1080 @ 1~60
1280 x 720 @ 1~60
1024 x 576 @ 1~60
620 x 360 @ 1~60
Output HD-SDI/3G-SDI
HDMI
RTSP / RTMP / NDI®|HX
USB 3.0 & 2.0
Color Space 4:2:2 (YCbCr) 10bit
Min. Illumination 0.1Lux



Function

White Balance Auto, Manual, Auto Tracking, One Push, Indoor, Outdoor
Focus Auto, Manual
Shutter Speed 1 to 1/10,000 Sec.



Lens

Lens 12X HD Optical Zoom, F1.5 ~ F3.0



PTZ

Pan, Tilt :Range Pan: 340°,
Tilt: +90 to -30°
Pan, Tilt :Speed Pan: 0° to +120°/s
Tilt: 0° to +80°/s
Presets 128 Positions
Field of View 72.5°



Standard

SMPTE SMPTE 292M, SMPTE 424M
IP Protocol TCP|IP, RTSP|RTMP



Audio

Input 3.5mm TRS Stereo Audio Port
Sample Rate 16/24/32 Bits



Physical

Camera Control Protocol: VISCA Interface: RS-232C IN & OUT, RJ-45 Remote Controller
Operation Temp 32° F – 104° F
Dimension 155mm x 160m x 170mm / 6.10″ x 6.92″ x 6.69″
Weight 1.35kg / 2.97lbs
Power 12VDC (+9 – +15VDC) PoE+ (IEEE802.3at Standard Required)

View full details
