AIDA Imaging HD-NDI-IP67 - Full HD NDI|HX IP Weatherproof POV Camera

The Full HD NDI|HX / IP Streaming Weatherproof POV Camera from AIDA brings IP and NDI output into an ultracompact form for POV streaming applications in broadcast, education, medical, live production, and other fields. This HD-NDI-IP67 model features weatherproofing, so it can be easily integrated into an outdoor environment. It outputs variable frame rate IP streaming via RTSP/RTMP and/or NDI|HX with up to 1080p60 resolution. A 10' long dongle cable carries both RTSP/RTMP streaming and NDI|HX over a single Ethernet cable, and it supports the VISCA-over-IP control protocol. The camera can be powered using the included power adapter or by using the included PoE dongle on a PoE-supported network with the dongle. It features a C/CS lens mount and comes with a 4mm HD lens pre-installed. NDI|HX is a bidirectional standard that allows video systems to identify and communicate with one another over IP, and to encode, transmit, and receive multiple streams of broadcast-quality, low latency, frame-accurate video and multichannel audio in real time.

Key Features

• Compact miniature camera for POV streaming applications in broadcast, education, medical, live production, sports, and other fields
• Weatherproof IP67 rating allows for extra protection against environmental elements
• Full HD 1/3" progressive scan CMOS sensor capable of 1080p60 NDI|HX video
• Accessible web UI to stream directly to social media platforms and control image parameters over IP
• Versatile design with top and bottom tripod mounts for unique shot creation
• Suited for outdoor shots and any new or existing NDI|HX setup
• C/CS lens mount
• 4mm HD lens pre-installed
• VISCA-over-IP control support

---

Specifications

Video

• Image Sensor: 1/3” Progressive CMOS
• Sensor Size: 5.346mm x 3.003mm (16.9)
• Effective Pixels: Horizontal: 1920, Vertical: 1080
• Pixel Size: 2.75 μm (H) x 2.75 μm (V)
• Resolution: 1080p, 1080i, 720p
• Resolution/Framerate: 1080 60p/59.94/50p/30p/29.97p/25p/24p; 1080 60i/59.94i/50i; 720 60p/59.94p/50p
• Output: IP (NDI|HX/SRT/RTMP/RTSP)
• Color Space: 4:2:2 (YCbCr) 10bit
• Min Illumination: 0.2Lux (day), 0.1Lux (Night)
• White Balance: Auto & Manual (9000 - 11,000 K)

Lens

• Lens: C/CS Mount (Default 4mm HD Lens with CAP)

Standard

• IP Protocol: UDP|IP, RTSP|RTMP, SRT, NDI|HX

Physical

• Camera Control Protocol: VISCA Over IP
• Operation Temp: 32°F - 104°F
• Dimensions: 78mm x 41mm x 41mm / 3.07” x 1.61” x 1.61” (with default WP cap)
• Weight: 454g / 1 lb (with default WP cap)
• Power: 12VDC (+9 - +15VDC) (PoE Adapter Included)
