AIDA Imaging HD-NDI3-120 – Full HD 120fps NDI|HX3 IP SRT PoE POV Camera

AIDA Imaging HD-NDI3-120 – Full HD 120fps NDI|HX3 IP SRT PoE POV Camera

$725.00 USD
$725.00 USD
Sale Sold out
The AIDA HD-NDI3-120 brings simultaneous IP and HDMI output into an ultracompact form for POV streaming applications in broadcast, education, medical, live production, and other fields. With NDI|HX3 and 120 fps frame rate this versatile camera is well-suited for high-speed shooting for instant replay.

Key Features

  • Simultaneous IP (SRT/RTSP/RTMP), NDI|HX3, and HDMI output in up to 1080p120 (HDMI and NDI|HX only)
  • IP and NDI over a single RJ-45 output
  • 3.5mm audio port for embedding audio into the IP/NDI signals
  • Includes a breakout cable with power and RS-485 serial control ports
  • C/CS lens mount
  • 4mm HD lens
  • 4-pin IRIS control port for compatible lenses
  • Top and bottom 1/4"-20 mounting threads

Specifications

Image Sensor 1/3" Progressive CMOS
Effective Pixels 1920 x 1080
Pixel Size 2.13 x 2.13 μm (V)
Output Resolution NDI|HX and HDMI ONLY: 1080p120, 1080p100 NDIHX 3 and Others: 1080p60, 1080p59.94, 1080p50, 1080p30p, 1080p29.97, 1080p25, 1080p24, 1080i60, 1080i59.94, 1080i50, 720p60p, 720p59.94p, 720p50p
Bitrate Control Variable, Constant
Video Bitrate up to 60mb/s
Color Space 4:2:2 (YCbCr) 10-Bit
Lens Mount C/CS Mount
Lens Included 4mm
Output 1 x HDMI (Preview) 1 x RJ45 (IP/NDI)
Audio 1 x 3.5 mm Input (for IP/NDI)
Audio Sample Rate 16/24/32 Bits
Other Ports USB C (Firmware) 4-Pin IRIS Port
Built-In Microphone No
Built-In Speaker No
Breakout Cable Connector Hirose
Breakout Cable 1 x RS-485 1 x Power 1 x 3.5mm audio input
Video Encoding H.264/H.265
Minimum Lux 0.2Lux (day), 0.1Lux (Night)
Camera Control Protocol: VISCA over IP
SMPTE Standards 292M, SMPTE 424M
Mount Type Top: 1/4"-20 Female Bottom: 1/4"-20 Female
Power 12 VDC (9 to 15 V) / POE+ (IEEE802.3at)
Operating Temperature 32 to 104°F / 0 to 40°C
Dimensions 3.35" x 1.93" x 1.93" / 85 x 49 x 49 cm
View full details
