Switchblade M9 Pro – Advanced vMix Desktop Live Production System


Compact yet powerful vMix production system with up to 8 physical inputs

  • Free US shipping on all orders over $200
  • 30 day returns (restock fee applies for some items)
  • In stock items ship next business day
Guaranteed Safe Checkout

The Switchblade M9 Pro is a compact and portable production switcher running vMix live switching and streaming software. Whether you want to stream your church worship services, town meetings, sporting events, or virtual conferences, the M9 Pro gives you the best combination of hardware and software to ensure your next event runs perfectly. For producers who need more functionality and performance for advanced productions, the M9 Pro is a valuable step up from the Switchblade M9.

This multi-camera streaming powerhouse can handle an incredible variety of media sources. Take your incoming cameras, add graphics, mix audio, and send to multiple destinations, both online and locally.


Technical Specifications
VersionvMix 4K
Max Input Resolution4096 x 2160
Graphic Overlays4 Overlays
Recorders2 independent channels
Streaming Outputs3 Outputs
NDI (Network Device Interface)Unlimited NDI inputs (depending on video settings) – 4 NDI outputs
SRT (Secure Reliable Transport)Unlimited SRT inputs (depending on video settings) – 4 SRT outputs
Fullscreen Output2 Outputs – View Program, Preview, or Multi-View on another monitor
External Output4 Outputs – View any video source via NDI, SRT, vMix Call or SDI (with SDI input/output option)
Virtual SetsBuilt-in and customizable virtual sets with full motion zoom and high-quality chroma keying
Titling Software
  • GT Designer Standard – Includes 100+ Built-In Animated Titles, Scoreboards, Tickers
  • GT Designer Advanced – Build custom animated titles, including using layered Adobe PSD files
PlaylistSwitch between multiple live inputs or prerecorded videos without manual intervention.
Video ListCreate playlists of video files to play in sequence – a great way to stream prerecorded content when your event is offline.
Remote Callers4 Callers using vMix Call
MultiCorderIsolated (ISO) source recording of multiple inputs simultaneous, with or without graphics overlays
ReplayvMix Replay – 1-channel instant replay and slow-motion playback
ScriptingAdvanced automation using VB.NET and web scripting
PTZ ControlControl most PTZ (Pan/Tilt/Zoom) cameras directly without the need for a separate controller
Color CorrectionProfessional color correction on every input, including lift, gamma, gain, luminance, hue, saturation with real-time vectorscope monitoring.
Processor16-core Intel Core i7-13700KF CPU
Memory32GB DDR4
Storage1TB NVMe Solid State Drive
GraphicsNVIDIA RTX 3060 Ti GPU
Video Inputs/Outputs4-channel HDMI or 3G-SDI inputs

  • Optional: Upgrade 3G-SDI inputs to bi-directional SDI input/output
  • Optional: Additional 4x 3G-SDI inputs
Audio Inputs/OutputsProfessional 2-channel stereo 1/4″ TRS analog inputs and outputs
Dimensions12.57″ x 6.78″ x 14.09″ (319mm x 172mm x 358mm)
Weight19 lbs (8.6 kg)

Additional information

Weight20 lbs
Dimensions18 × 16 × 10 in
Primary Input

4x HDMI, 4x 3G-SDI, 4x 3G-SDI In/Out/Sync

Secondary Input

None, 4x 3G-SDI Inputs
